There are a wide variety of sensors with analog outputs on the market, but the most common outputs are 0-10V and 4-20mA, which are supported by all our devices. Some of them are capable of measuring other less standard values. To find out more, consult the specific manual for that device.
Not directly, the digital inputs of the devices are of potential-free type or NPN type. Therefore, if we want to connect a sensor with PNP output, we must use an intermediate element such as a relay to convert to NPN.
Devices that have digital outputs are of the open collector type, therefore they do not provide voltage to their output, but rather close to GND, therefore they are of the NPN type.
The SDI-12 standard can manage dozens of addresses on a single bus, but each device is limited by the available memory, CPU and power resources. For this reason, 2 probes can be connected to Mex03, 8 probes to Mex06 and 16 probes to IPex12.
The standard indicates up to 60 meters, although this will always depend on the installation location and the cable used.
It depends on the section of the cable used, but if the output is by voltage, an adequate section must be guaranteed to avoid a significant drop in the cable that affects the reading. If a large distance needs to be covered (tens of meters), it is better to use a sensor with a 4-20mA output, since it avoids the problem of voltage drops in the cable and is also more immune to external interference.
Normally, and especially with wireless communication systems, there are connection drops due to the network, temporary loss of coverage, weather conditions, etc. This can cause the device to stop communicating with the platform for a few hours, but the device continues to function and record data, so as soon as it regains connection it will send all the stored information.
You can create as many plots as you need. Ingrovia is designed to adapt to the actual size of your farm, without limiting your growth.
Yes. You can invite as many users as you need and assign them different access levels: full control to help you manage and configure your property, or view-only access. This way, each person only sees or manages what they are authorized to.
A farm is the main management unit and can encompass several spaces. Each space represents a specific plot, sector, or area, with its own sensors, data, and irrigation settings.
From Ingrovia You can easily manage irrigation: activate manual watering, schedule times, or configure automatic rules by area. All from a single platform, with real-time information for better and more controlled watering.
We offer various contract models to suit the needs of each farm. Our team will help you find the option that best fits your facility and working methods.
You can register as many devices as you need. The platform is designed to grow with you and centralize information for your entire operation.
Yes, provided they are compatible, we can integrate them so you can view their data directly on the platform. If the sensor isn’t integrated from the start, we’ll explore the possibility of configuring it or developing the necessary integration.
Yes. You can select the parameters you want to view, adjust ranges, and save custom views to quickly and clearly access the most relevant information.
