IPex08

IPex08 - Accessories

Expansion module with 8 digital outputs for latch valve control and 8 configurable digital inputs for counters or detection.

To request additional documentation, write to soporte@odins.es

Technical specifications

8 digital outputs for direct control of 6 to 12VDC latch type valves or control via 24VAC valve latch relay
8 digital inputs with potential-free contacts for counters (50Hz)
Possibility of expanding the number of I/Os with more IPex08 connected on the bus
Communication ports:
-1 port for long distance communications (up to 2 km)
-1 CAN Bus 2.0 port
